Kia Cee'd: Specifications & Consumer information / Refrigerant label
The refrigerant label is located on the underside of the hood.
Air conditioner compressor label
A compressor label informs you the type
of compressor your vehicle is equipped
with such as model, supplier part number,
production number, refrigerant (1)
and refrigerant oil (2). ...
Declaration of conformity
■ Example
The radio frequency components of the
vehicle comply with requirements and
other relevant provisions of Directive
1995/5/EC.
Further information including the manufacturer's
de ...
